GL.iNet has added the Comet X to its expanding Comet KVM range, with this model taking a more rack-focused approach than the earlier single-system units. Rather than being built around remote access to 1 machine, the Comet X is aimed at users who need to manage several nearby systems from a single KVM point, such as servers, workstations, test machines, or homelab hardware. It keeps the same general idea of browser and app-based remote control, but applies it to a 4-device setup with PoE support, local control options, and a chassis intended to fit more naturally into rack environments. At the time of writing, GL.iNet has shown the Comet X on its official pages, but has not confirmed a final price or general availability date
The Comet X is built around a 4-system KVM layout, with 4 HDMI inputs for video capture and 4 USB-C device ports for connecting the controlled host machines. It also includes 1 HDMI output, allowing a local monitor to be connected directly to the unit rather than relying only on remote access through a browser or app. This is an important distinction from many smaller remote KVM devices, as the Comet X is not only intended to sit between a user and a remote machine, but also to act as a local switching and troubleshooting point when working directly at the rack.
For peripheral support, the unit includes 7 USB 2.0 Type-A host ports, rated at 5 V/0.5 A per port, which can be used for external peripherals and local interaction. Networking is handled through a 1GbE RJ45 port with 802.3af/at PoE support, while a USB-C power input is also available as an optional 5 V/3 A PD-compatible power source. This gives the device some flexibility in how it is deployed, although the presence of PoE is clearly one of the more rack-oriented parts of the design, as it reduces the need for a separate power adapter in suitable network environments.
Internally, the Comet X uses a quad-core ARM Cortex processor, 1 GB of DDR3L memory, and 64 GB of eMMC storage. The storage is intended for firmware, system use, and image storage, including ISO files for OS deployment or recovery tasks. The unit runs Linux 6.1 and supports up to 4K@30FPS video handling. It also includes a 3.69-inch TFT touchscreen on the front, which is used to show device status information such as IP details, online or offline state, and active sessions. Physically, the unit measures 170 x 90 x 40 mm, weighs 560 g, and includes brackets for both 10-inch and 19-inch rack mounting.
| Specification | Details |
|---|---|
| Product Name | GL.iNet Comet X |
| KVM Type | Quad-port remote KVM |
| Controlled Systems | Up to 4 host computers |
| Operating System | Linux 6.1 |
| CPU | Quad-core ARM Cortex |
| Memory | 1 GB DDR3L |
| Storage | 64 GB eMMC |
| HDMI Input | 4 x HDMI IN |
| HDMI Output | 1 x HDMI OUT |
| USB Host Ports | 7 x USB 2.0 Type-A, 5 V/0.5 A per port |
| USB Device Ports | 4 x USB 2.0 Type-C |
| Network Port | 1 x RJ45 |
| Ethernet Speed | 10/100/1000 Mbps |
| PoE Support | 802.3af/at |
| Optional Power Input | USB-C, 5 V/3 A, PD-compatible |
| Display | 3.69-inch TFT touchscreen |
| Video Resolution | Up to 4K@30FPS |
| Function Button | 1 |
| Dimensions | 170 x 90 x 40 mm |
| Weight | 560 g |
| Rack Mounting | Compatible with 10-inch and 19-inch racks, brackets included |
The Comet X uses GL.iNet’s GLKVM software platform, which is shared across the company’s current Comet KVM range. This allows connected systems to be accessed through a web browser or through GL.iNet’s own applications for Windows, macOS, Android, and iOS. The core purpose is to provide direct keyboard, video, and mouse access to the attached machines, including scenarios where the target system has no working operating system, no remote desktop service, or needs BIOS-level access. For server maintenance, OS installation, remote troubleshooting, and recovery work, this is the main difference between a hardware KVM and normal remote access software.
The GLKVM software also includes a number of management features that are relevant to a multi-system KVM setup. These include video quality adjustment up to 4K@30FPS, remote file transfer, audio output, virtual keyboard support, Wake-on-LAN, 2-factor authentication, and support for accessories such as ATX boards and Fingerbot devices. The Comet X also supports remote access methods including GL.iNet’s own access service, as well as Tailscale, ZeroTier, and NetBird, depending on how the user wants to expose or restrict access. This makes it possible to keep the device limited to a local network, integrate it into an overlay VPN, or use a more direct remote access method where appropriate.
Where the Comet X is more unusual is in combining remote KVM access, local KVM operation, PoE power, rack mounting, and control of up to 4 systems in 1 device. The current small remote KVM market is mostly built around 1 host system per unit, while traditional multi-port KVM switches are often focused on local switching rather than browser or app-based remote management. The Comet X sits between those categories. It is not just a remote dongle for 1 computer, and it is not simply a local HDMI and USB switch. Its main role is to provide centralized access to several nearby systems while still allowing remote control, local fallback access, touchscreen status information, and ISO-based recovery from the same unit.
The main difference between the Comet X and the rest of GL.iNet’s Comet KVM range is the number of systems it is designed to manage. Models such as the standard Comet, Comet PoE, Comet Pro, Comet 5G, and Comet Q are built around access to a single connected machine, with the exact feature set changing depending on the model. Some focus on compact remote access, some add PoE, some add stronger standalone hardware, and the Comet 5G adds cellular connectivity for fallback access. The Comet X changes the role of the device by moving from a 1-system KVM into a centralized 4-system unit.
That makes the Comet X less of a direct replacement for the other Comet models and more of a separate branch in the same product family. A single-system Comet device may still make more sense for users who only need access to 1 PC, NAS, mini PC, or remote workstation, especially where size, cost, or cellular failover matters more than managing several systems in 1 place. The Comet X is better aligned with rack or bench environments where multiple machines are physically grouped together and need to be accessed from 1 management point. Its trade-off is that some features found elsewhere in the Comet line, such as built-in 5G failover, are not currently listed for this model.
| Feature | Comet | Comet PoE | Comet Pro | Comet 5G | Comet Q | Comet X |
|---|
| Model Number | GL-RM1 | GL-RM1PE | GL-RM10 | GL-RM10RC | GL-RMQ1 | GL-RM4PE |
| Main Role | Entry-level remote KVM | Remote KVM with PoE | Wi-Fi 6 remote KVM with touchscreen | Remote KVM with 5G RedCap and failover | USB-C all-in-one KVM | Quad-port remote KVM with PoE |
| Target Use Case | Home lab, single PC, remote access | Server room, IT maintenance, cleaner rack cabling | Wireless remote access to 1 machine | Out-of-band access where LAN may fail | USB-C devices, laptops, phones, Mac mini, portable setups | Rack or bench management of up to 4 nearby systems |
| Controlled Systems | 1 | 1 | 1 | 1 | 1 | Up to 4 |
| Video Input Style | HDMI-based KVM | HDMI-based KVM | HDMI-based KVM | HDMI-based KVM | Built-in USB-C cable with DP Alt Mode | 4 x HDMI IN |
| Local Video Output | Model dependent | Model dependent | HDMI passthrough | HDMI passthrough | Browser-based control from connected device workflow | 1 x HDMI OUT |
| Maximum Resolution | 4K@30FPS | 4K@30FPS | 4K@30FPS | 4K@30FPS | 1080P@60FPS | 4K@30FPS |
| Network Connection | Ethernet | 1GbE with PoE | Wi-Fi 6 and Gigabit Ethernet | Ethernet, Wi-Fi, 5G RedCap, 4G fallback | Wi-Fi 6 | 1GbE with PoE |
| PoE Support | No | Yes | No | No | No | Yes |
| Wi-Fi Support | No | No | Wi-Fi 6 | Wi-Fi 6 | Wi-Fi 6 | Not listed |
| Cellular Support | No | No | No | 5G RedCap with 4G fallback | No | No |
| Internal Storage | 32 GB eMMC | 32 GB eMMC | 32 GB eMMC | 64 GB eMMC | 512 MB NAND | 64 GB eMMC |
| Memory | 1 GB DDR3L | 1 GB DDR3L | 1 GB DDR3L | 1 GB DDR3L | 512 MB LPDDR4 | 1 GB DDR3L |
| Processor | ARM Cortex, quad-core | ARM Cortex, quad-core | ARM Cortex, quad-core | ARM Cortex, quad-core | ARM Cortex, quad-core | ARM Cortex, quad-core |
| Touchscreen | No | No | 2.22-inch touchscreen | 3.69-inch touchscreen | 1.8-inch touchscreen | 3.69-inch TFT touchscreen |
| Browser Access | Yes | Yes | Yes | Yes | Yes | Yes |
| App Access | GLKVM app support | GLKVM app support | GLKVM app support | GLKVM app support | Browser-first workflow | GLKVM app support |
| Tailscale Support | Yes | Yes | Yes | Yes | Yes |
| ZeroTier Support | Not listed | Not listed | Not listed | Not listed | Yes | Yes |
| NetBird Support | Not listed | Not listed | Not listed | Not listed | Not listed | Yes |
| Self-hosted Deployment | Yes | Yes | Yes | Yes | Not clearly listed | Yes |
| Local Keyboard/Mouse/Monitor Use | Limited compared with traditional local KVMs | Limited compared with traditional local KVMs | Limited compared with traditional local KVMs | Nearby wireless local access | USB-C device-focused | Yes, via local keyboard, mouse, and monitor |
| Rack Mounting | Not a primary design focus | 10-inch rack mount support available | Not a primary design focus | Not a primary design focus | Portable design | 10-inch and 19-inch rack brackets included |
| Release Status | Available | Available | Available | Available | Upcoming / VIP or pre-launch stage | Upcoming |
| Key Limitation | Single-system control | Single-system control | No built-in cellular failover | Still single-system control | Lower resolution than HDMI-based models | No confirmed price or release date yet |
GL.iNet has not yet confirmed the final price or launch date for the Comet X. The official product listing currently presents the device as an upcoming quad-port remote KVM, and GL.iNet’s wider product pages also label the Comet X as upcoming rather than available to purchase. GL.iNet has also publicly referenced beta tester recruitment for the Comet X, which suggests the device is still in a pre-release stage rather than a finished retail launch. Until GL.iNet confirms availability, pricing, regional distribution, and whether there will be any early-bird or campaign pricing, the Comet X should be treated as announced but not yet released.
